XAHS365 Md
28
C
OMPRESSOR
/
ENGINE SPECIFICATIONS
Value
Compressor/engine
(3)
Number of compression stages 1
Maximum (unloading) pressure 14 bar(e)
Normal working pressure 12 bar(e)
up to altitude of
(4)
4000 m
Minimum working pressure 4 bar(e)
Free air delivery
(5)
358 l/s
Compressor cooling system oil
Mercedes diesel engine, water-cooled OM 441 LA
Engine speeds:
- Maximum load speed 1600 r/min
- Unloading speed 1000 r/min
Electrical system, negative earthed 24 V
Batteries:
- Number 2
- Voltage/capacity 12 V/143 Ah
- Cold cranking current:
- SAE J537h 900 A
- DIN 72311 630 A
Weight
- Standard unit DRY 3800 kg
- Standard unit WET 4300 kg
Filling capacities
Compressor oil system ± 66 l
Engine oil system ± 15 l
Fuel tank 334 l
Engine cooling system 54 l
Compressor
Air receiver capacity 192 l
Temperature above ambient of air leaving air outlet
valves ± 60 °C
Max. ambient temperature at sea level, normal working
pressure and max. load speed 50 °C
Sound power level (LW) complies with 84/532//533/EEC
and 85/406/EEC limits 102 dB(A)
Sound pressure level according to ISO 2151 74 dB(A)
Dimensions
Overall length, drawbar raised ± 4210 mm
Overall width ± 1810 mm
Overall height ± 2369 mm
Minimum turning circle Ø 8462 mm
Towing
Compressors with parking brake only
Max. towing speed
(6)
25 km/h
Michelin tyres:
- Type XC PR10
- Size 6.5R16 in
- Pressure, front/rear 4.5/4.5 bar(e)
Compressors with pneumatic brakes (optional equip-
ment)
Max. towing speed
(6)
80 km/h
Michelin tyres:
- Type XCA 118N TL
- Size 225/75R16 in
- Pressure, front/rear 4.5/4.5 bar(e)
