Reference Name
F1 Circuit Breaker (10 A)
G1 Alternator
G2 Battery
H1 Temperature Alarm Lamp
H2 General Alarm Lamp
K0 Starter Solenoid (part of M1)
K1 Shut-down Relay
K2 Blocking Relay
K3 Override Start Relay
K4 Start Relay
K9 Auxilary Relay Safety Circuit
M1 Starter Motor
N1 Overspeed Module
P1 Hourmeter
S1 Contact Switch (Off-On-
Override-start)
S2 Temperature Switch Engine
S3 Oil Pressure Switch Engine
S4 Temperature Lamptest Switch
S5 Temperature Switch Compressor
S32 Test Button Overspeed
Y1 Fuel Solenoid Valve
Y20 Solenoid for Overspeed
Protection Valve
V1 Diode
V2 Diode

Atlas Copco XAS 67 Dd C3 APP Specifications

General

Brand	Atlas Copco
Model	XAS 67 Dd C3 APP
Category	Air Compressor
Language	English
