- 89 -
Reversing lever
Reversing lever
Check reversing lever (1) for ease of motion.
If fitted, apply general purpose grease via the grease
nipple until fresh grease can be seen emerging from
the bush.
If grease nipples are not fitted, then apply oil to the
reversing lever bush.
Lubrication points
Lubricate all moving parts and pivot pins at
the overrun coupling
All moving parts of drawbar, handbrake lever, spring
actuator, reversing lever, linkages etc. are to be oiled
or greased as required.
Heigth adjusting device
Grease sliding locations on the height-
adjusting device
Oil threaded parts and grease toothed parts.
50 km after initial start-up, then every
2,000 kilometres or annually.
(1)
50 km after initial start-up, then every
2,000 kilometres or annually.
Every 2,000 kilometres or annually.
