- 110 -
Box/support mounted
XAS 67 - XAS 130 /
XATS 67 - XATS 125
XAS 77 - XAS 150 /
XAS 97 - XAS 185
Length (X) mm 2018 2018
in 79 79
Width (Y) mm 1040 1040
in 41 41
Height (Z) mm 970/1230 970/1230
in 38/48 38/48
Weight
(ready-to-operate)
kg 790/840 800/850
lbs 1742/1852 1763/1873
Weight (dry) kg 725/775 735/785
lbs 1599/1709 1621/1730
XY
Z
