DESIGN DATA
Compressor
Engine
Number of compression stages
XATS 138 PE
XATS 250 PE
XATS 138 PE/XATS 250 PE
with aftercooler
XAHS 108 PE
XAHS 190 PE
XAHS 108 PE/XAHS 190 PE
with aftercooler
1 1 1 1
Designation Unit
XATS 138 PE
XATS 250 PE
XATS 138 PE/XATS 250 PE
with aftercooler
XAHS 108 PE
XAHS 190 PE
XAHS 108 PE/XAHS 190 PE
with aftercooler
Make Kubota Kubota Kubota Kubota
Type V2403-CR-T-E5B V2403-CR-T-E5B V2403-CR-T-E5B V2403-CR-T-E5B
Coolant ParCool EG ParCool EG ParCool EG ParCool EG
Number of cylinders 4 4 4 4
Bore mm 87 87 87 87
in 3.43 3.43 3.43 3.43
Stroke mm 102.4 102.4 102.4 102.4
in 4.03 4.03 4.03 4.03
Swept volume l 2.4 2.4 2.4 2.4
cu in 146.5 146.5 146.5 146.5
Power output at normal shaft speed (kW) kW 48.6 48.6 48.6 48.6
BHP 65.2 65.2 65.2 65.2
Output according to ISO 9249G ISO 9249G ISO 9249G ISO 9249G
Capacity of oil sump:- Initial fill l 9.5 9.5 9.5 9.5
US gal 2.5 2.5 2.5 2.5
Capacity of oil sump : - Refill (maximum)
(2)
l 9 9 9 9
US gal 2.4 2.4 2.4 2.4
Capacity of cooling system l 11.5 11.5 11.5 11.5
US gal 3.0 3.0 3.0 3.0
