ALTITUDE UNIT PERFORMANCE CURVE
Max. allowable working pressure as a function altitude and ambient temperature.
9/jul/07
3 281
6 562
9 843
13 124
0 ft
14 32 50 68 86 104 122
0
1000
2000
3000
4000
-10.0 0.0 10.0 20.0 30.0 40.0 50.0
XAMS 407
XAMS 850 CD7
125 psi
8.6 bar
9/jul/07
3 281
6 562
9 843
13 124
0 ft
14 32 50 68 86 104 122
0
1000
2000
3000
4000
-10.0 0.0 10.0 20.0 30.0 40.0 50.0
XATS 377
XATS 800 CD7
149 psi
10.3 bar
ALTITUDE IN M
ALTITUDE IN FT
ALTITUDE IN M
ALTITUDE IN FT
TEMPERATURE IN °F TEMPERATURE IN °F
TEMPERATURE IN °C TEMPERATURE IN °C
