LCR40 User Guide November 2021 – Rev 7
Page 11
Testing Resistors
Resistance values ranging from 0.5Ω to 2MΩ can be measured, with a
minimum resolution of about 0.3Ω. Resistance is measured using a DC signal
with a peak voltage of 1V (across an open circuit) and a peak current of about
3mA (through a short circuit).
Resistor results: Following analysis, the
resistance value is displayed.
Low Resistance/Inductance
Low value inductors (<5µH) and low value resistors (<10Ω) are treated as a
special case by the LCR40. This is because low value inductors and low value
resistors can exhibit very similar characteristics at the test frequencies
available from the LCR40.
The following message is displayed:
Pressing the scroll-off button will
display the values of resistance and
inductance that the LCR40 has
measured.
The test frequency displayed is the
frequency used for the measurement of
the inductance.
Please note that probe compensation is particularly important when
analysing low value inductors, capacitors and resistors.
Resistance
332.2k
Low Resistance
and Inductance
Resistance
1.3 ohms
Inductance
0.6uH
Test frequency
200kHz
