Low Value Capacitors
There is a vast range of low value capacitors available. Types include ceramic,
polyester, polystyrene and mylar dielectric capacitors. Generally, low value
capacitors tend to be unpolarised. Minimum capacitance resolution is about
0.2pF.
Capacitor test frequency: The LCR40 uses a high purity sine wave signal of
1kHz, 15kHz or 200kHz to analyse these types of capacitors. The frequency is
automatically selected to give the best possible measurement resolution.
The following table shows the test frequencies used for various capacitance
ranges:
The capacitance ranges for each test frequency shown in the table above is
approximate. Effects such as leakage, dielectric dissipation and ESR can
influence the frequency that the LCR40 selects for your particular capacitor.
Capacitor results: Following analysis of the capacitor, the capacitance value
is displayed first. Press the scroll-off button to display the frequency at
which the capacitance was measured.
Capacitance
48.3pF
Test frequency
200kHz
