Atlona AT-HDSync - Specifications

2
SPECIFICATIONS
Model Name AT-HDSync
Technical
HDMI
™
compliance HDMI
™
1.3c
DVI compliance DVI 1.0
HDCP compliance Yes
Video bandwidth Single-link 225MHz (6.75Gbps)
Video support Up to 1080p60 & WUXGA (1920x1200@60Hz)
Input 1x HDMI
™
+ 1x RS-232
Output 1x HDMI
™
HDMI
™
connector Type A (19-pin female)
RS-232 connector DE-9 (9-pin D-sub female)
Flash EEPROM 256 byte (non-volatile)
Mechanical
Housing Metal enclosure
Dimensions
[L x W x H]
Model 91 x 80 x 27mm (3.6” x 3.1” x 1.1”)
Package 270 x 175 x 80mm (10.6” x 6.9” x 3.2”)
Weight Model 240g (8.5oz)
Fixedness Wall-mounting case with screws
Power supply 5V DC
Power consumption 4 Watt (max)
Operation temperature
0~40°C (32~104°F)
Storage temperature
-20~60°C (-4~140°F)
Relative humidity 20~90% RH (no condensation)
