External Program and Data Memory Characteristics
Symbol Parameter
12 MHz Oscillator Variable Oscillator
Units
Min Max Min Max
1/t
CLCL
Oscillator Frequency 0 24
MHz
t
LHLL
ALE Pulse Width 127 2t
CLCL
-40
ns
t
AVLL
Address Valid to ALE Low 28 t
CLCL
-13
ns
t
LLAX
Address Hold After ALE Low 48 t
CLCL
-20
ns
t
LLIV
ALE Low to Valid Instruction In 233 4t
CLCL
-65
ns
t
LLPL
ALE Low to PSEN Low 43 t
CLCL
-13
ns
t
PLPH
PSEN Pulse Width 205 3t
CLCL
-20
ns
t
PLIV
PSEN Low to Valid Instruction In 145 3t
CLCL
-45
ns
t
PXIX
Input Instruction Hold After PSEN 0 0
ns
t
PXIZ
Input Instruction Float After PSEN 59 t
CLCL
-10
ns
t
PXAV
PSEN to Address Valid 75 t
CLCL
-8
ns
t
AVIV
Address to Valid Instruction In 312 5t
CLCL
-55
ns
t
PLAZ
PSEN Low to Address Float 10 10
ns
t
RLRH
RD Pulse Width 400 6t
CLCL
-100
ns
t
WLWH
WR Pulse Width 400 6t
CLCL
-100
ns
t
RLDV
RD Low to Valid Data In 252 5t
CLCL
-90
ns
t
RHDX
Data Hold After RD 0 0
ns
t
RHDZ
Data Float After RD 97 2t
CLCL
-28
ns
t
LLDV
ALE Low to Valid Data In 517 8t
CLCL
-150
ns
t
AVDV
Address to Valid Data In 585 9t
CLCL
-165
ns
t
LLWL
ALE Low to RD or WR Low 200 300 3t
CLCL
-50 3t
CLCL
+50
ns
t
AVWL
Address to RD or WR Low 203 4t
CLCL
-75
ns
t
QVWX
Data Valid to WR Transition 23 t
CLCL
-20
ns
t
QVWH
Data Valid to WR High 433 7t
CLCL
-120
ns
t
WHQX
Data Hold After WR 33 t
CLCL
-20
ns
t
RLAZ
RD Low to Address Float 0 0
ns
t
WHLH
RD or WR High to ALE High 43 123 t
CLCL
-20 t
CLCL
+25
ns
A.C. Characteristics
Under operating conditions, load capacitance for Port 0, ALE/PROG, and PSEN = 100 pF; load capacitance for all
other outputs = 80 pF.
AT89C52
17
