51
4929B–AUTO–01/07
ATA6264 [Preliminary]
Configuration of watchdog trigger:
For the configuration of the watchdog prescaler, a special serial interface command is
necessary.
Note: a, b, and c to be set as defined in Table 16-1
The status of the watchdog prescaler is indicated in the status register.
Description
MSByte LSByte
Hex Code7654321076543210
Configure prescaler 0110000011110abc 60Fx
Table 16-1. Watchdog Prescaler Command
Selection Bits
Retrigger Time (ms)abc
0 0 0 Set to default (16 ms)
0014
0108
01116
10032
10164
110128
1 1 1 Set to default (16 ms)
