HOSES:
Your regulator was function tested and is ready for use from the factory. You will need to install
your high pressure gauge, instruments and low pressure accessories such as inators. If you are in
doubt on how to do this, see your Atomic Aquatics professional retailer for assistance.
LOW PRESSURE HOSES: (LP thread size 3/8"-24)
Your regulator has either 5 low-pressure (LP) ports on the swivel end of the rst stage
(T3, T2x, ST1, M1, B2) or 7 low pressure ports (Z2/Z3) in a xed orientation. Choose the ports
that give you the best orientation for your particular set-up. The LP port plugs can be removed by
unscrewing with a 5/32" (4mm) hex wrench. Install the LP hoses into the port and snug up with a
wrench. Do not overtighten as this will not improve the seal and may damage the threads.
HIGH PRESSURE HOSES: (HP thread size 7/16"-20)
Your regulator has 2 high pressure ports (marked HP) on either side of the body. The HP ports and
plugs are larger in size than the LP plugs. Remove the plugs with the same hex wrench and install
the high pressure gauge hose into the high pressure port and snug it with a wrench.
SYSTEM SET-UP
CAUTION
Do not assemble any low pressure hoses to the HP port of the rst stage. The hose
could rupture and could cause serious personal injury. Do not assemble the high
pressure gauge to the low pressure port or the gauge will not indicate tank pressure.
2 HIGH
PRESSURE PORTS
5 LOW PRESSURE PORTS
ON FIRST STAGE SWIVEL
