Pulldown Removal (PDR)
Both Connect-AC converters can apply
2:2 pulldown to incoming interlaced
and psf signals in order to restore their
original 23.98p, 24p, 25p, 29.97p or 30p
formatting.
Please note that 3:2 pulldown is NOT
supported by the Connect-AC.
When the Connect is in Converter
Mode and locked (Rx) to an interlaced
signal (1080i) that has had pulldown
applied, the pulldown (PDR) function
can be used.
2:2 Pulldown Removal Operation
To activate the 2:2 pulldown function,
press the MODE button once. The PDR
LED will turn BLUE.
The unit will then convert as follows:
INPUT OUTPUT
23.98psf > 23.98p
24psf > 24p
25psf > 25p
29.97psf > 29.97p
30psf > 30p
50i > 25p
60i > 30p
NOTE: If the input signal is not
interlaced, the PDR function is
disabled.
Pressing the MODE button a third time
turns off the pulldown.
Operation
Atomos Connect-AC User Manual V1.0 5
BLUE
PDR
