Atomos Connect S2H - Page 2

Atomos Connect. User Manual V1.0 2
CONNECT H2S
HDMI>HD-SDI
(Part No. ATOMH2S001)
 Connect H2S
 9V AC Adaptor
 12V DC Travel Adaptor
 NP Series Battery
 AC Battery Charger
CONNECT S2H
HD-SDI>HDMI
(Part No. ATOMS2H001)
 Connect S2H
 9V AC Adaptor
 12V DC Travel Adaptor
 NP Series Battery
 AC Battery Charger
NOTE:
This User Guide pertains to both Connect units. Each Connect box contains 1 converter only.
What’s in the box
HDMI IN
2 x HD-SDI OUT/TPG OUT
LOOP OUT/TPG OUT HD-SDI IN
HDMI OUT/TPG OUT
