MDSC-1000B 使用指南
stipulated in the hardware specifications (Refer to the “parameters and properties” for
details);
◆ Please don’t install the product in such places where the magnetic filed is too
strong, or there is direct sunlight or high temperature, or strong mechanical vibration.
And don’t use the product in the places where there exist inflammable gases, or
vapour, or dusts. Otherwise, explosion hazard may occur;
◆ Please don’t use the product in the environment where drastic temperature change
may occur or the humidity is very large. Otherwise, condensed water may be
produced in the interior of the equipment and causes damage to the product;
◆ Please ensure that all the cable joints be firmly connected to this product. In case
of loose connection, the wrong input or output signals may be generated;
◆ During usage, it is not allowed to use any tool to contact the display panel. Any
damage to the panel due to over external force should be borne by the user;
◆ To avoid being electric shocked, please first cut off the power source before
connecting the product to its power supply;
◆ The input voltage of the product is DC24V±20％. Please regularly check whether
the DC power is stable or not;
◆ The port of NPN and PNP can only be connected to the DC system less than 48V;
◆The sensor’s wire routing should be separated from that of the power line,
especially when the wiring place has strong interference caused by frequency
converter, etc.
III. Parameters and properties of the product
MDSC-1000B metal double-sheet detector
Rectangular sensor: 45mm * 30mm * 12mm, with
