Atonm MDSC-1000B - Panel and Function Description

MDSC-1000B 使用指南
4
standard configuration of 5m cables
Circular sensor: 18mm (Diameter) * 50mm(Length), with
standard configuration of 5m cables
Circular sensor: 30mm (Diameter) * 65mm (Length), with
standard configuration of 5m cables
Input voltage
DC24V/500mA
Control output
1. NPN single and double-sheet switch signal output,
maximum drive: 50mA/48V
2. PNP single and double-sheet switch signal output,
maximum drive: 50mA/48V
3. double-sheet relay signal output (Normally open),
maximum: 1A/60VDC
Note: The switch signal output width of the single and
double sheets is more than 50ms.
Testing materials
Steel sheets, iron sheets, copper sheets, aluminum sheets,
zinc-plated sheets, and stainless steel sheets, etc.
Testing thickness
0.05~4.5mm for iron sheets, copper sheets and
stainless steel sheets, 0.1~10mm for aluminum sheets
Response speed
0~1200Pcs/min
IV. Panel and function description of the product
