Product Introduction
APS series power supply is designed for the needs of electronic training
schools, communication maintenance technicians and related engineering
research and development personnel. The current best-stability series voltage
stabilization scheme is adopted for this product, and the digital MCU chip is
used for control. With very high stability and low ripple, simple operation and
control, and complete protection functions, it provide the user with convenient
and reliable high quality power supply.
Product Specification
Power input: refer to the voltage identification at the tail of the product (other
input voltage can be customized).
Rated value/dimensions/weight:
Model
Voltage Regulation
Range
Current Regulation
Range
Input Power
Weight
APS15-3A
0-5V/0-15V
0-0.5A/0-3A
124VA
2.4Kg
Dimensions：(L) 215mm *(W) 88mm * (H)150mm
Technical Parameters
Constant Voltage mode (CV):
Output voltage range: 0 to rated voltage continuously adjustable.
Power supply variation rate: ≤ 0.01%+3mV.
Load variation rate: ≤ 0.01%+3mV (rated current ≤ 3A).
4
Protection function: overvoltage protection/overcurrent protection (cut-off
mode, delay start)/overheat protection.
Other functions: locking function, voltage coarse/fine adjustment, sound
function, 5V/15V voltage switching, 0.5A/3A current switching.
Cooling mode: temperature controlled fan, forced air cooling.
Operating environment: 0℃~40℃, <80% (indoor use).
Storage temperature and humidity: -10 ~70 , <70%.
Packing list: host × 1, power line × 1, user manual × 1.
