Atten ST-862D - Schematic Diagram of the Whole Equipment

ST-862D
ST-862D
Shortcut Key 1/
Menu Key/
Menu Turn-up Key
Blowing Plus Key
Blowing Minus Key
Temp Plus Key
Shortcut Key 2/
Menu Exit Key
Power Key
Hot Air Handle
Interface
Schematic Diagram of the Whole Equipment
Connection Diagram for the Whole Equipment
Note: The hot air handle connected with host
well before sell.
2
Shortcut Key 1/
Menu Key/
Menu Turn-down Key
Temp Minus Key
