ATTO Technology ExpressSAS R608 - Page 34

31
Exhibit 6-4
Mini-SAS
Connector
I2C Header PHYs Backplane Backplane
Slots
I2C
Address
R608 - 2 x4 Backplanes (See example 1.)
J3 P7 0-3 1 1-4 C0
J2 P6 4-7 2 1-4 C0
R608 - 1 x6 Backplane
J3 P7 0-3 1 1-4 C0
J2 n/a 4-5 1 5-6 n/a
R608 - 1 x8 Backplane
J3 P7 0-3 1 1-4 C0
J2 P6 4-7 1 5-8 C2
R60F – 2 x4 Backplanes
J1 P8 0-3 1 1-4 C0
J2 P9 4-7 2 1-4 C2
J3 n/a n/a n/a n/a n/a
J4 n/a n/a n/a n/a n/a
R60F - 1 x6 Backplanes
J1 P8 0-3 1 1-4 C0
J2 n/a 4-5 1 5-6 n/a
J3 n/a n/a n/a n/a n/a
J4 n/a n/a n/a n/a n/a
R60F - 1 x4 & 1x6 Backplane (See example 3.)
J1 P8 0-3 1 1-4 C0
J2 P6 4-7 2 1-4 C2
J3 n/a 8-9 2 5-6 n/a
J4 n/a n/a n/a n/a n/a
R60F - 1 x16 Backplane
J1 P8 0-3 1 1-4 C0
J2 P8 4-7 1 5-8 C2
J3 P6 8-11 1 9-12 C0
J4 P6 12-15 1 13-16 C2
SES-I2C Wire chart for R608 or R60F (Examples start on page 35)
