2. Check the there is oil in the engine and petrol in the tank.
3. Check tyre pressures.
The drawbar attachment height of the towing vehicle can vary. To accommodate adjustment,
a screw link is located beneath the drawbar. This should be lengthened or shortened
so that the cutting deck is horizontal to level ground. (This ensures a better cutting
efficiency)
TO ADJUST
1. Unlock the locking nut (A)
2. Lengthen the link to lower the front of the deck or shorten to raise the deck.
3. Once the deck is level, re-tighten locking nut (A).
A
QUICK OFFSET DRAWBAR
Pull back the locking pin; slide the drawbar to the desired position, and release the
locking pin into the securing hole, as shown.
Locking
pin
