13
Mower Cutting Height
The main cutting height adjustment is achieved by using the screw jack, to raise or lower the
cutting deck as necessary.
Turn the handle to raise or lower as necessary
Observe all safety precautions; keep hands and feet away from rotor and other moving
parts. Keep spectators at a safe distance.
1) Make sure there is a gap between the blades and the ground / crop
2) Select an area clear of loose debris that could be picked up.
3) Set the engine choke, and suitable idling speed with the throttle.
4) Place one foot on top of the deck body to give a firm and balanced position. Pull
the starter cord firmly, allowing the cord to return to return to the housing slowly (one
or two strong pulls should start the engine).
5) After a few seconds warming up at idling speed, move the throttle
Cutting Height Adjustment
Start The Engine
