ATV Flail Mower Assembly
Number Part Number Name & Specifications Quantity Remark
1 GB1152-89 Oil cup M6 1
2 GB6170-86 Mut N12 2
3 GB97.1-85 Plain Washer 12 4
4 MFP120.00.03 Protection Casing 1
5 8-A Weldment 1
6 GB5783-86 Bolt M12x35 1
7 MFP120.00.03 Handle 1
8 9 GB276-94 Bearing 61904 1
9 TR200.00.123 Bearing Seat 1
10 GB301-95 Bearing 51104 1
11 GB70-85 Screw M8x30 1
12 TR200.00.120 Adjusting Screw 1
13 MFP120.00.17 Sheath For Handle 2
14 6 Cover For Tyre 4
15 MFP120.00.14 Bearing 80205 2
16 8 GBT278-94 Tyre 4
17 MFP120.00.01 Rubber Cover 2
18 6 Supporting Bracket For 4
19 MFP120.00.10 Tyres 4
20 1 Nut M10 4
21 MFP120.00.02 Plain Washer 10 2
22 7 GB889-86 Blot M10x75 1
23 GB97.1-85 Tension Spring 1
24 GB5782-86 Bolt M12x70 1
