Installation Procedure
1) Cut a hole in the ceiling on the desired mounting location of the loudspeaker with a diameter of 167
mm. The included cutout template can be used for marking.
2) Provide the loudspeaker connection cable through the mounting hole.
3) Take the loudspeaker, and remove the front grill.
The front grill can be removed by rotating the mounting clips outwards and pushing them down. The
fixing screws will push the front grill out.
4) Pull the mounting clips up again, and rotate them inwards, making the speaker fit through the
mounting hole in the ceiling.
