17
Crankshaft drive
The steel crankshaft runs in six bearings. The main bearing is
58 mm in diameter, while the conrod bearing is 47.8 mm in dia-
meter.
The torsion vibration damper is located at the front end and is
configured as a viscodamper*.
451_027
Crankshaft
Conrod
Circlip
Gudgeon pin
Conrod bearing cap
Piston
Conrod bushing
Conrod bearing shell
Cylinder included angle in mm 88
Block height in mm 220
Conrod length in mm 144
Crankshaft bearings 6
Main bearing diameter in mm 58
Conrod bearing diameter in mm 47.8
Specifications of the cylinder block
