Ref no Part no Description Qt
vailable Y/N
1 Wrap board 1 N
2 Front board 1 N
3 B1.35 B Woofer 1 Y
4 GRI-69 Front grille 1 Y
5 Support board 1 N
6 Wrap board 1 N
7 Back board 1 N
8 Air Flow 69 BX port 2 Y
9 Paper tube 152mm 1 Y
10 Wood base 1 N
11 Bass Eq 1 Y
12 Spacer 48mm 4 Y
13 Insert nut 4 y
14 Screw 4x20 head 8 4 Y
18 Amplifier (see separate parts list) 1 N
19 Screw 4x20 10 Y
20 ACE BASS badge 1 Y
21 Rubber feet 20Øx10 4 Y
22 K31-3005 Blue led (mounted in pos 20) 1 Y
