Parts list B1.36 Europe 230V 50Hz
POSITION PART NO DESCRIPTION
B1.36 AMP ASSY
RED LED POWER ADL-6S702 LED RED 5MMD
Q208 ATR-2SB817 TR 2SB817 (A1492)
Q209 ATR-2SC3421 TR 2SC3421
Q207 ATR-2SD1047 TR 2SD1047 (C3856)
POWER SWITCH CAPACITOR ECW-400V102K CAP Y-SUPPRESSOR 0.001UF/400V +-10%
LED BUSHING EMX-1018 LED BUSHING 5MM
POWE CORD BUSHING EMX-7005-K AC CORD BUSHER ST-100N
FUSE HOLDER FUH-1006 FUSE HOLDER 5*20MM VDE/UL OP520
FUSE FUS-01-1001SC FUSE VDE/UL 5*20 1A/250V TSD
BINDING POST RED JK1-L01-G7013 BIND POST GOLDEN RED D=6mm
BINDING POST BLACK JK1-L01-G7014 BIND POST GOLDEN BLK D=6mm
BINDING POST BLACK PLUG DM04P0002 PLUG FOR BINDING POST BLK
BINDING POST RED PLUG DM04P0003 PLUG FOR BINDING POST RED
VR KNOB M11-P605-02 VR-KNOB 18*16
POWER SWITCH SWK-7009 SWROCK R-30NS RH SERIAL
VR101, LEVEL VR VRR-7068 A50K*1 L=15MM
VR102, LOW PASS VR VRR-7069 B20K*4 L=15MM
POWER CORD WPC-7109 POWER CORD 6FT VDE
T402, MAIN TRANSFORMER XFM-3013 XFORMER(K29-2021C) AC 28.0*2 FOR B.5
SPEAKER IN / OUT PCB
X-OVER CAPACITOR ECJ-100A107K CAP ELNP 100V 100UF +-10%(A TYPE)
MISCELLANEOUS
BLUE LED KIT INCL ZENER DIODE K31-3005 LED BLUE 5MMD
LED BUSHING FOR BLUE LED EMX-1018 LED BUSHING 5MM
RCA CABLE 6M WAS-7398 WIRE ASS'Y 1P RCA PLUG 6M BLK GOLDEN
