Parts list B1.36 Europe 230V 50Hz
POSITION PART NO DESCRIPTION
15V POWER SUPPLY PCB
D306.D307 ADD-1N4004 DIODE, 1N4004
IC304.IC306 AIC-KA7815 IC KA7815
IC303.IC305 AIC-KA7915 IC KA7915
Q301 ATR-2SC3421 TR 2SC3421
C301-308 ECE-025T227M CAP, ELEC 220UF 25V +/-20%
R301 ERB-202K101J RES MO 2WK 100 +-5%
R302 ERB-202K151J RES MO 2W K 150 +-5%
R303 ERC-121Y103J RES, 10K OHM 1/6W +/-5%
R304 ERC-121Y473J RES, 47K OHM 1/6W +/-5%
POWER SUPPLY PCB
D403 ADB-KBU6G DIODE BRIDGE KBU6G 6A/400V
D401.D402 ADB-W02 DIODE BRIDGE W02 1.5A/200V
D404 ADD-1N4004 DIODE, 1N4004
RE01 ARL-01-7002 RELAY 12V 1P1T MIT-SH-112LM
C405,C406 ECD-150T104M CAP CER 150V 0.1uF+-20%
C401-C404 ECE-025T107M CAP, ELEC 100UF 25V +/-20%
C409.C410 ECE-063V688M-2 CAP ELE 63V 6800uF+-20% 105°C
C407 ECW-275V104K X-CAP 14104 0.1uF/275V
C408 ECW-400V102K CAP Y-SUPPRESSOR 0.001UF/400V +-10%
T401, STAND BY TRANSFORMER XFM-3012 XFORMER (K29-2020C) AC 15.0V*2
To Next Page
