Parts list B1.36 Europe 230V 50Hz
POSITION PART NO DESCRIPTION
PRE AMP PCB
D101,102 ADD-1N4148* DIODE, 1N4148
ZD101 ADZ-UZ3.3BM DIODE ZENER UZ 3.3BM 1/2W
IC101-105 AIC-TL072 IC DUAL OP AMP TL072
Q103 ATR-2SC1815 TR 2SC1815
Q102 ATR-2SD655E TR 2SD655E
Q101 ATR-2SK363 TR 2SK363
C105,115 ECD-050T470M CAP CER 50V 47P +-20%
C122 ECE-025T107M CAP, ELEC 100UF 25V +/-20%
C117-120 ECE-050T106M CAP, ELEC 10uF 50V +-20% P5
C116 ECE-050T107M
CAP, ELEC 100UF 50V +/-20% 85℃
C114 ECJ-050T106M CAP ELNP 50V 10uF +-20%
C123 ECJ-050T475M CAP ELNP 50V 4.7uF +-20%
C101,C102 ECM-100T102J CAP, MYLAR 1000PF 100V +/-5% P5
C107,108 ECM-100T104J CAP, MYLAR 100NF 100V +/-5%
C103,104,136 ECM-100T333J CAP, MYLAR 33NF 100V +-5% P5
C111 ECM-100T823J CAP MYLAR 100V 0.082 +-5%
C110,C143,C144 ECZ-063T104J-1 CAP, POLYFILM 0.1uF 63V +/-5%
C112 ECZ-063T224J-1 CAP, POLY METL 220NF 63V +/-5%
C138 ECZ-063T474J-1 CAP, POLYFILM 470NF 63V +/-5%
R144 ERB-202K220J RES MO 2W K 22 +-5%
R111,112 ERB-501Y102J RES MO 1/2W Y 1K +-5%
R143 ERC-121Y101J RES, 100 OHM 1/6W +/-5%
R135 ERC-121Y103J RES, 10K OHM 1/6W +/-5%
R136,R141,R126 ERC-121Y104J RES, 100K OHM 1/6W +-5%
R137 ERC-121Y123J RES, 12K OHM 1/6W +/-5%
R127 ERC-121Y154J ERC CF 1/8W Y 150K +-5%
R101,131,R102 ERC-121Y221J RES, 220 OHM 1/6W +/-5%
R132,R145 ERC-121Y223J RES, 22K OHM 1/6W +/-5%
