Parts list B1.36 Europe 230V 50Hz
POSITION PART NO DESCRIPTION
R116 ERC-121Y393J RES, 39K OHM 1/6W +/-5%
R133,R130 ERC-121Y395J RES CF 3M9 1/8W +-5%
R115 ERC-121Y472J RES, 4K7 OHM 1/6W +/-5%
R140 ERC-121Y473J RES, 47K OHM 1/6W +/-5%
R134,R129 ERC-121Y562J RES, 5K6 OHM 1/6W +/-5%
R119 ERM-121Y1003F RES MF 1/8W Y 100K +-1%
R125 ERM-121Y1102F RES MF 1/8W Y 11K +-1%
R105,106 ERM-121Y1502F RES MF 1/8W Y 15K +-1%
R113,114,121-124,R103,104 ERM-121Y1802F RES MF 1/8W Y 18K +-1%
R142 ERM-121Y2001F RES MF 1/8W Y 2K +-1%
R128 ERM-121Y2701F RES MF 1/8W Y 2K7 +-1%
R118 ERM-121Y3902F RES MF 1/8W Y 39K +-1%
R107-110 ERM-121Y4303F RES MF 1/8W Y 430K +-1%
JK1, RCA JACK JK3-L02-7006 JACK RCA L 2P
SW101,SW102. AUTO / MAF SWITCH SWS-G7002 TOGGLE SW T8019L-TECQ
