Audio Pro B1.39 - Component Lists; Power Amp & Supply Components

B1.39
PART-NUMBER
DESCRIPTION
LOCATION
ASS'Y PCB POWER AMP AND SUPPLY BOARD
ADB-BR62
DIODE BRIDGE BR62 200V 6A
D06
AIC-NJM2072D
IC SIGNAL LEVEL SENSOR SYSTEM NJM2072D
IC3
AIC-TA7317P
IC TA7317P
IC2
AIC-TL071
IC TL071
IC1
ARL-01-7001
RELAY 24V 1P1T OMIT-SS-124LM
K1
ADD-1N4004*TAP52
DIODE RECTI 1N4004 TAPING 52MM
D03-05
ADD-1N4148*TAP52
DIODE SWITCH 1N4148 52MM
D01,02
ADZ-1N5231B
DIODE ZENER 1N5231B 0.5W 5.1V +-5%
ZD3
ADZ-1N5245B
DIODE ZENER 1N5245B 0.5W 15V +-5%
ZD1-2
ATR-BC546B
TR BC546B (&)
Q01,03,14,16
ATR-BC556B
TR BC556B
Q02,04,15
ATR-BF422
TR BF422
Q06
ATR-BF423
TR BF423
Q05
ECD-050T102M
CAP CER NP 1NF/50 +-20%
C16
ECD-050T104M
CAP CER 50V 0.1UF +-20%
C09
ECD-050T221M
CAP CER 50V 220P +-20%
C04,05,06
ECD-050T222M
CAP CER 50V 0.0022uF +-20%
C01
ECD-050T223M
CAP CER 50V 0.022UF +-20%
C08
ECD-050T470M
CAP CER 50V 47PF +-20%
C07
ECE-025T107M
CAP ELE 25V 100UF +-20%
C42,43
ECE-025T226M
CAP ELE 25V 22U +-20%
C14
ECE-025T476M
CAP ELE 25V 47U +-20%
C12,13
ECE-050T106M
CAP ELE 50V 10UF +-20%
C02,03,10,18,26,45,46
ECE-050T474M
CAP ELE 50V 0.47UF +-20%
C15
ECE-100T105M
CAP ELE 100V 1U +-20%
C25
ECM-050T104J
CAP MYLAR 50V 0.1u +-5%
C11
ECM-100T104J
CAP MYLAR 100V 0.1uF +-5%
C23,24
ERB-251Y121J
RES FR 1/4W Y 120 +-5%
R14,18
ERB-251Y150J
RES MO 1/4W Y 15 +-5%
R15
ERB-251Y221J
RES FR 1/4W Y 220 +-5%
R20
ERB-251Y2R2J
RES FR 1/4W Y 2.2 +-5%
R19,21
ERB-251Y391J
RES FR 1/4W Y 390 +-5%
R10,11
ERC-121Y102J
RES CF 1/8W Y 1K +-5%
R02
ERC-121Y103J
RES CF 1/8W Y 10K +-5%
R01,43,45
