Audio Pro B5 - Volume Control; Controls and Indicators

6
audio pro
CONTROLS AND INDICATORS
1) Low level input (MONO)
from amplifier
2) Standby mode switch-
Auto or ON
7) Speaker Level input
(from amplifier)
8) Mains switch
9) Fuse ( T1A )
10) Mains cord (230V)
WARNING !
To reduce the risk of electric shock, do not open or remove cover or back. Do not expose this appliance to rain or moisture. In case of malfunction consult qualified service
personel.
The exclamation point, within an equilateral triangle, is intended to alert the user of the presence
of important operating and maintenance (servicing) instructions in the literature accompanying the
appliance.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
The lightning flash with arrowhead, within an equilateral triangle, is intended to
alert the user of the presence of uninsulated "dangerous voltage" within the
product´s enclosure; that may be of sufficient magnitude to constitute a risk of
electric shock to persons.
3) Volume control
4) Low pass crossover control
5) ON/OFF indikator (Red)
6) Speaker Level output
(to satellite speakers)
