CONTROLS AND INDICATORS
1) Low level input (MONO)
from amplifier
2) Speaker Level input
(from amplifier)
6) Fuse
7) Mains switch
8) Mains cord (115V)
WARNING !
To reduce the risk of electric shock, do not open or remove cover or back. Do not expose this appliance to rain or moisture. In case of malfunction consult qualified service
personel.
The exclamation point, within an equilateral triangle, is intended to alert the user of the presence
of important operating and maintenance (servicing) instructions in the literature accompanying the
appliance.
The lightning flash with arrowhead, within an equilateral triangle, is intended to
alert the user of the presence of uninsulated "dangerous voltage" within the
product´s enclosure; that may be of sufficient magnitude to constitute a risk of
electric shock to persons.
3) Speaker Level output
(to satellite speakers)
4) Low pass crossover control
5) Volume control
1
2
3
4
5
6
7
8
