Audio Technica AT-SP65XBT User Manual

4
Part names and functions
1
Status indicator lamp / Microphone
Lights in blue when the power is on, and flashes blue while
searching for devices to pair with. Also, the microphone is built
into this part.
2
Speaker unit
3
Battery jack (USB Type-C
TM
)
Use to connect the included USB charging cable and charge the
product.
4
Charging indicator lamp
Lights in red when charging, and turns off when charging is
complete.
5
External input jack
Use to connect an audio device with the included audio cable for
wired connections.
6
Volume buttons
Use + and - to adjust the volume, and to skip forward or back.
7
Power supply button
Turns the power on/off.
8
Multifunction button
Use to play/pause music and answer/end phone calls.
9
Bluetooth button
Use for pairing.
Accessories
• USB charging cable
(1 m (3.3’), USB Type-A - USB Type-C)
• Audio cable
(0.6 m (2’), 3.5 mm (1/8”) stereo
mini-plugs)
1
2
6 7 8 9
3 4 5

Audio Technica AT-SP65XBT Specifications

Speaker Specifications

speaker unit size	73 mm
maximum output	12 W
frequency response	90 to 18, 000 Hz

Microphone Specifications

microphone type	Electret condenser
polar pattern	Omnidirectional

Communication Specifications

bluetooth version	5.0
maximum communication range	approx. 10 m
frequency band	2.402 GHz to 2.480 GHz

Battery and Power

power supply	Lithium polymer battery
charging time	Approx. 3 hours
operating time	Max. approx. 12 hours

Weight and Dimensions

dimensions	270 mm × 105 mm × 113 mm
weight	1.42 kg
operating temperature	5°C to 40°C
