5
■ Accessories
• Cable (1.2 m (3.9’) / 3.5 mm
(1/8”) gold-plated stereo
mini-plug/L-type)*
• USB charging cable
(30 cm (12”))
• Airplane adapter • Case
*The diameter is 2.5 mm (3/32”) on the straight plug side and 3.5 mm (1/8”) on the L-shaped plug side.
Part names and functions
L/R (left/right)
indicator
Slider
Arm
Joint
Headband
Earpad
Touch panel (L side)
Use to play and pause
music, control calls, adjust
volume, and switch to the
noise-cancelling function
(NC) or hear-through
function (HT).
Connector jack
Use to connect the included
cable for the playthrough
function.
Subswitch button
Turns the quick hear-through
function on and off.
Battery jack
Use to connect the included
USB charging cable and
charge the product.
Multi-indicator lamp
Displays the operating status and
battery level of the product.
Power switch
Turns the power on
and off.
Housing
An internal microphone
is built into the L (left)
side housing.
Function indicator lamp
Displays the operating status of
the noise-cancelling function (NC)
and hear-through function (HT).
