Audio Technica ATR2100x-USB User Manual

16
Element: Dynamic
Polar Pattern: Cardioid
Frequency Response: 50 – 15,000 Hz
Power Requirements: USB Power (5V DC)
Bit Depth: Up to 24 bit
Sample Rate: 44.1 kHz/48 kHz/96 kHz/192 kHz
Controls: On/off switch; headphone volume control
Weight: 268 g (9.5 oz)
Dimensions: 183.0 mm (7.20") long, 51.0 mm (2.01") maximum body diameter
Output Connector: USB-C/XLR
Headphone Output Power: 10 mW @ 16 ohms
Headphone Jack: 3.5 mm TRS (stereo)
Accessories Included: Stand clamp for ⅝"-27 threaded stands, tripod desk stand, 2 m (6.6') USB-C to USB-C cable
(USB On-The-Go Compliant), 2 m (6.6') USB-C to USB-A cable, 3 m (9.8') XLRF to XLRM cable
System Requirements: Macintosh: Mac OS X; USB 1.0 or 2.0; 64 MB RAM (minimum)
Windows: Windows 7/8/10; USB 1.0 or 2.0; 64 MB RAM (minimum)
†In the interest of standards development, A.T.U.S. offers full details on its test methods to other industry professionals on request.
Specifications are subject to change without notice.
ATR2100x-USB Specifications
†
LEGEND
200 Hz
1 kHz
5 kHz
8 kHz
SCALE IS 5 DECIBELS PER DIVISION
240˚
180˚
210˚
270˚
300˚
330˚
0˚
150˚
120˚
90˚
30˚
60˚
12" or more on axis
LEGEN
D
Frequency in Hertz
Response in dB
10 dB
100
50
200
10k
5k
1k
500
2k
20k
LEGEND
200 Hz
1 kHz
5 kHz
8 kHz
SCALE IS 5 DECIBELS PER DIVISION
240˚
180˚
210˚
270˚
300˚
330˚
0˚
150˚
120˚
90˚
30˚
60˚
12" or more on axis
LEGEND
Frequency in Hertz
Response in dB
10 dB
100
50
200
10k
5k
1k
500
2k
20k
Frequency Response
Polar Pattern

Audio Technica ATR2100x-USB Specifications

General

Type	PC microphone
Bit rate	24 bit
Sample rate	192 kHz
Volume control	Rotary
Microphone frequency	50 - 15000 Hz
Device interface	USB/3.5 mm
Connectivity technology	Wired
On/off switch	Yes
Product color	Black
Compatible operating systems	Windows, Mac
Power source	USB
Operating voltage	5 V
Cables included	USB Type-C to USB Type-A, USB Type-C to USB Type-C
Number of products included	1 pc(s)

Weight and Dimensions

Height	183 mm
Diameter	51 mm
Microphone weight	268 g
