AudioArts Engineering R-60 - Page 11

Page 3 - 14
R-60 / Nov 1994R-60 / Nov 1994
R-60 / Nov 1994R-60 / Nov 1994
R-60 / Nov 1994
CC
CC
C
ONSOLEONSOLE
ONSOLEONSOLE
ONSOLE
L L
L L
L
OGICOGIC
OGICOGIC
OGIC
& I/O C & I/O C
& I/O C & I/O C
& I/O C
ONNECTIONSONNECTIONS
ONNECTIONSONNECTIONS
ONNECTIONS
DMP-60 OutputDMP-60 Output
DMP-60 OutputDMP-60 Output
DMP-60 Output
(CT2, DMP-60 load sheet dwg)
Pin 1 - MICROPHONE 1 OUTPUT, SHIELD
Pin 2 - AUDIO COMMON
Pin 3 - MICROPHONE 1 OUTPUT, HIGH
Pin 4 - MICROPHONE 1 OUTPUT, SHIELD
Pin 5 - AUDIO COMMON
Pin 6 - MICROPHONE 1 OUTPUT, HIGH
Pin 7 - MICROPHONE 2 OUTPUT, SHIELD
Pin 8 - AUDIO COMMON
Pin 9 - MICROPHONE 2 OUTPUT, HIGH
Pin 10 - MICROPHONE 2 OUTPUT, SHIELD
Pin 11 - AUDIO COMMON
Pin 12 - MICROPHONE 2 OUTPUT, HIGH
LS-60 Inputs 1 & 2LS-60 Inputs 1 & 2
LS-60 Inputs 1 & 2LS-60 Inputs 1 & 2
LS-60 Inputs 1 & 2
(CT3, LS-60 load sheet dwg)
Pin 1 - LINE 2 LEFT INPUT, SHIELD
Pin 2 - LINE 2 LEFT INPUT, LOW
Pin 3 - LINE 2 LEFT INPUT, HIGH
Pin 4 - LINE 2 RIGHT INPUT, SHIELD
Pin 5 - LINE 2 RIGHT INPUT, LOW
Pin 6 - LINE 2 RIGHT INPUT, HIGH
Pin 7 - LINE 1 LEFT INPUT, SHIELD
Pin 8 - LINE 1 LEFT INPUT, LOW
Pin 9 - LINE 1 LEFT INPUT, HIGH
Pin 10 - LINE 1 RIGHT INPUT, SHIELD
Pin 11 - LINE 1 RIGHT INPUT, LOW
Pin 12 - LINE 1 RIGHT INPUT, HIGH
LS-60 Inputs 3 & 4LS-60 Inputs 3 & 4
LS-60 Inputs 3 & 4LS-60 Inputs 3 & 4
LS-60 Inputs 3 & 4
(CT2, LS-60 load sheet dwg)
Pin 1 - LINE 4 LEFT INPUT, SHIELD
Pin 2 - LINE 4 LEFT INPUT, LOW
Pin 3 - LINE 4 LEFT INPUT, HIGH
Pin 4 - LINE 4 RIGHT INPUT, SHIELD
Pin 5 - LINE 4 RIGHT INPUT, LOW
Pin 6 - LINE 4 RIGHT INPUT, HIGH
Pin 7 - LINE 3 LEFT INPUT, SHIELD
Pin 8 - LINE 3 LEFT INPUT, LOW
Pin 9 - LINE 3 LEFT INPUT, HIGH
Pin 10 - LINE 3 RIGHT INPUT, SHIELD
Pin 11 - LINE 3 RIGHT INPUT, LOW
Pin 12 - LINE 3 RIGHT INPUT, HIGH
CC
CC
C
ONSOLEONSOLE
ONSOLEONSOLE
ONSOLE
L L
L L
L
OGICOGIC
OGICOGIC
OGIC
& I/O C & I/O C
& I/O C & I/O C
& I/O C
ONNECTIONSONNECTIONS
ONNECTIONSONNECTIONS
ONNECTIONS
Key diagram showing back of
typical 12-pin I/O connector
plug, with pin numbers oriented
as they would be seen while
wiring. Beveled corners
correspond to PCB mounted
mating sockets.
5 46
8 79
11 1012
2 13
Page 3 - 13
