AudioBahn DUB100 - Theile; Small Parameters; Woofer Parameter Table; Dimensions Data; EBP Parameter

Model #
DUB100
DUB200
DUB500
Fs
38 Hz
32 Hz
29.7Hz
Qts
0.74
0.72
0.64
Qes
0.92
0.83
0.77
Qm
s
3.923
5.397 3.79
Vas (Liters)
24.0 Liters
63.99 Liters
86.5 Liters
Vas (Cu. Ft.)
0.85 Cu.Ft.
2.26 Cu. Ft.
3.1 Cu. Ft.
Re
1.5 ohms
1.5 ohms
1.5 ohms
Le
0.43mH
0.43 mH
0.43 mH
Mmd
114.5 Grams
126.5 grams
267 Grams
Xmax
+/- 8 mm
+/- 8 mm
+/- 8 mm
RMS
300 watts
400 watts 500 watts
Sd
330 sqcm
480 sqcm 770 sqcm
Freq. Resp.
23Hz-500Hz
20Hz-500Hz
18Hz-500Hz
Efficiency(2.8V)
91.1 dB 92.7 dB
93.9 dB
EBP
42
39 39
Depth
5 1/4" 6 3/8"
7 1/8"
Hole
91/8"
10 7/8" 13 5/8"
Diamater
10"
12 1/8"
15 1/8"
Displacement
0.12 Cu. Ft. 0.23 Cu.Ft.
0.38 Cu.Ft.
Dimensions
An EBP of less then45isSUGGESTED for only a sealed box and greater then 65 for a ported box.
Vas does not represent the volume of a Box. Vas is just a parameter used when calculating abo
x.
DUB Woofer Paramaters
Theile / Small Parameters
06
