DVD PLAYER MAIN UNIT
1. Main Power ON/OFF Switch
2. Volume decrease button
3. Volume increase button
4. IR sensor
5. Play/Pause Button
6. Previous button
7. Next Button
8. LCD Display/Drive Access panel
9. 3.5mm Stereo headphone output
10. 3.5mm AV link output
11. SD/MMC/MS Card slot (SDHC compatible)
12. USB host port
13. 12VDC Link output
14. 12VDC input
MONITOR
1. Main Power ON/OFF Switch
2. Volume decrease button
3. Volume increase button
4. Left Button
5. Menu Button
6. Right Button
7. 12VDC Link Cable input
8. 3.5mm AV link input
9. 3.5mm Stereo headphone output jack
Instruction Manual
