Main waveforms graphical representation
sin sinF sinH TrPs shp 0 TrPs shp 64 TrPs shp 120
TrSw shp 0 TrSw shp 64 TrSw shp 127 TrSq shp 0 TrSq shp 64 TrSq shp 127
Saw shp 0 Saw shp 64 Saw shp 127 Sup1 / Sup2 SwHs SqHs
Sqr shp 0 Sqr shp 64 Sqr shp 120
MIXER
The traditional source mixer menu, allowing to balance each oscillator and the white noise source level.
The output of the mixer is sent to the filter.
MIX1 mx2 mx3 nze
84 65 0 25
1. Oscillator 1 volume
2. Oscillator 2 volume
3. Oscillator 3 volume
4. White noise volume
Audiothingies MicroMonsta 2 user manual v2.1 16
