LFO | Low frequency oscillator
3 LFOs are available per voice.
They can be assigned in the modulation matrix.
LFO1 wav spd mod
sin 48 vce
They all have the same parameter set :
1. N/A
2. wav : LFO waveform
3. spd : LFO speed
LFO can be synchronized to the tempo by setting its speed above 127 (different synchorized
values are available)
If you need a speed that is not reachable with the parameter, use the matrix to offset LFO speed
4. mod : LFO mode (see below)
Bipolar LFO waveforms
They start from 0, go up first, then down, oscillating between -0.5 and 0.5 and return to 0 at the end of
their cycle.
They are best used to modulate a parameter around its current value.
Their polarity can be reversed in the matrix by setting a negative modulation amount.
sin tri saw squ
Not shown :
• s&h : sample & hold, a new value is calculated at each cycle
• rnd : like s&h, but continuously random waveform
Audiothingies MicroMonsta 2 user manual v2.1 19
