Audiovox AWM820 User Manual

IDENTIFICATION OF CONTROLS / CONNECTIONS
1) Tuning Up / Minute Set Button
2) Tuning Down / Hour Set Button
3) Mute / AS/PS / Loud Buttons
4) Time Set Button
5) Display Window
6) Alarm Set / Alarm On/Off Buttons
7) Button Reset
8) Preset Buttons
9) Cassette Fast Forward Button
10) Cassette Rewind Button
11) Cassette Player
12) Cassette Eject Button
13) Speaker Selector
14) 1/8” Auxiliary Input Jack
15) Stereo Headphone Jack
16) Audio Adjust Button
17) Power Switch w/Volume Control
18) Source Selectors
19) Car Antenna Jack 75 Ω
20) FM Antenna Terminals
21) RCA Auxiliary Input Terminals
22) Harness
1
14
15
16
17
18
13 12
32
1 5
4
7
11
9
10
8
6
1920
2122

Audiovox AWM820 Specifications

General

Brand	Audiovox
Model	AWM820
Category	Car Receiver
Language	English
