Setting Up and Installing Your Kit
NOTE: The XM
®
signal can be received and pro-
cessed virtually anywhere as long as there
are no obvioussatellite signal obstructions
such as high terrain, trees, overhangs, etc.
In placing the antenna, therefore, these factors
must be taken into account .
Boom Box XMB10 Controls
The Xpress XM
®
Boom Box XMB10 provides Power
ON/OFF and VOLUME +/- pushbuttons. A power-on LED
Installation/Wiring Precautions
1. If using the adapter, make sure the adapter cable
is not connected to an AC wall outlet until all inter-
connections have been made and verified. The
adapter power cable should be connected last.
2. Incorrect installation may cause damage to the
system.
3. For antenna positioning, refer to the Antenna
Aiming procedure outlined in the Xpress XM
®
Satellite Radio Receiver User Guide, 128-7454.
XMB10 Boom Box
(P/N 144-2484)
1 pc.
Contents XMB10
Users Guide
P/N 128-7546
1 pc.
AC/DC Power Adapter
(P/N 136-3990)
1 pc.
Antenna
(P/N 118-1155)
1 pc.
