10
Dust cover 1 8 Pitch adjust
Power switch 2 9 RPM selector
Power LED 3 10 Cueing lever
PUCK 4 11 Tone arm lock
Anti shock screw 5 12 Line-Out
Alignment screw w/ cover 6 13 Mains power cord
Counter weight 7
Inbetriebnahme und Nutzung
Connection
CONNECT THE POWER CORD (13) TO AN AC OUTLET. CONNECT LINE OUT RCA CONNECTORS (12) LOCA-
TED ON THE UNIT BACK TO YOUR EXTERNAL AMPLIFIER TO LISTEN TO THE MUSIC.
Counter Weights
Adjust:
Abspielen von Schallplatten
• Remove the stylus protection. Make sure the tone arm is detached from its tone arm rest.
• Select PHONO on your stereo and adjust the RPM corresponding to the record you like to listen.
• DJ! Put a record on! Use the „PUCK“, if needed.
• Lift the tonearm from the rest and slowly move it to the edge
of vinyl. The platter will start rotating automatically. Put it down
onto the desired position / track.
• At the end of the record, put the tone arm back to the tone arm
rest slowly.
