Auping Aureo - Replacing the floor light

• Remove the covering.
• Replace the protective glass and the lamps-
hade.
• Put the plug into the socket.
Replacing the floor light
• Turn off the power.
• Pull the plastic end out of the lamp stem (fig.
15).
• Separate the plastic halves (fig. 16).
• Remove the bulb from the bayonet fitting
(fig. 17).
• Use a 24V 2W/4W bulb.
• Place the new bulb into the bayonet fitting.
• Replace the plastic halves on the fitting.
• Push the wires back into the lamp stem (fig.
18).
• Put the whole fitting back into the lamp
stem.
If the continuously burning floor night light
disturbs you during the night, the bulb may be
removed.
GB9
fig. 14
fig. 13
fig. 12
fig. 15
fig. 16
fig. 18
fig. 17
