AUSA C300H - Page 46

C300H / C300HI / C300H x4 / C300HI x4
C350H / C350HI / C350H x4 / C350HI x4
44
Decals / labels / identification plates all markets (except USA)
STICKER:
FUEL TYPE INDICATION
REFERENCE: DESCRIPTION: QUANTITY:
43.01356.00 INDICATIVE STICKER 90x45 FUEL 1
POSITION:
On the right tank of the machine, next to the fuel cap, aligned with the vertical
outer wall of the tank.
STICKER:
EC INDICATION
REFERENCE: DESCRIPTION: QUANTITY:
45.19101.00 INDICATIVE STICKER 70x70 2
POSITION:
On the left side of the machine, at the bottom inner side of the front fenders,
aligned on its upper side with mark id 58.01353.01 “To hoist machine”.
STICKER:
HYDRAULIC OIL TYPE
REFERENCE: DESCRIPTION: QUANTITY:
43.01352.20 INDICATIVE STICKER 70x32 HYDRAULIC OIL 1
POSITION:
On the left-hand side tank, below the filler cap, aligned with the inner edge of the
tank, and centered with the cap.
