C300H / C300HI / C300H x4 / C300HI x4
C350H / C350HI / C350H x4 / C350HI x4
67
Starter switch (fig. 1)
See section STARTING THE ENGINE
a- In this position the ignition and the engine are disconnected.
b- Ignition on. The engine pre-heating system and the lamp on the control panel are
activated for a few seconds.
c- Starter. Turning the key to position (c) starts the engine.
Before re-starting the engine, the key should first be switched to position (a).
Fuse box (fig. 2)
This is located at the right of the steering column, next to the starter switch.
See the section ELECTRIC CIRCUIT in this Operator’s and Safety Manual to identify
the number and function of each fuse.
Instrument Panel
and controls
(fig. 2) (fig. 1)
a
b
c
