C300H / C300HI / C300H x4 / C300HI x4
C350H / C350HI / C350H x4 / C350HI x4
73
WARNING
Before each period of operation, check the forklift for correct operation of the
steering, brakes, hydraulic controls, instruments and safety equipment. Check
the neutral position of the FNR switch. A machine that runs correctly is more
efficient and can prevent accidents. Make all necessary adjustments or repairs
before you operate the machine.
Entering and leaving the operator cabin (fig. 1)
Don’t hold and pull of the steering wheel to come in/out the forklift, use the handles
located on the overhead guard and always place your foot on the rough bands of the
step, to prevent any downfall when you come in or come out.
Standard seat adjustment (fig. 2, 3, 4)
Each day, before operating the dumper, adjust your seat to a position in which you feel
comfortable.
Pull the lever (a) to up to unlock the seat. Slide the seat forward or backwards to reach
the desired position.
Releasing the leaver the seat locks.
The damping of the seat can be adjusted between 50 and 130 Kg, depending upon
the operator’s weight; to do so turn knob (b) clockwise or counter-clockwise in order to
adjust properly the seat damping.
For correct adjustment of the damping, with the operator sitting the needle (c) should
remain within the range of green scale into the gauge.
Using the lever (d) located on the left side of the seat backrest, the backrest inclination
can be changed. Pulling down the lever the backrest unlocks. Adjust the backrest and
release the leaver to lock again.
Ensure that you fasten your seatbelt.
Operating
the forklift
(fig. 1)
(fi g. 4) (fi g. 3) (fi g. 2)
a
c
b
d
