AUSA C300H - Page 51

C300H / C300HI / C300H x4 / C300HI x4
C350H / C350HI / C350H x4 / C350HI x4
49
Decals / labels / identification plates all markets (except USA)
STICKER:
AUSA STICKER
REFERENCE: DESCRIPTION: QUANTITY:
13.12136.00 AUSA STICKER 2
POSITION:
On both sides of the mast, above the beam, with its lower side aligned at 4ft 95
in from the ground, above the sticker ref. 45.01352.00 “Dangerous area”, and
0.3937 in away from it.
STICKER:
INDICATION TRANSFER BOX OIL.
REFERENCE: DESCRIPTION: QUANTITY:
43.00396.02 INDICATIVE STICKER 60x95 1
POSITION:
Into the engine compartment on the external face of the joystick control valve
support, above “Brake fluid indication” sticker.
STICKER:
NOT USE WITHOUT AUTHORIZATION
REFERENCE: DESCRIPTION: QUANTITY:
02.00777.00 INDICATIVE STICKER 50x120 ENGLISH 1
POSITION:
Top left-hand corner of the dashboard, aligned on its left side with sticker nº
12.12010.00 “Safety warning”.
