C300H / C300HI / C300H x4 / C300HI x4
C350H / C350HI / C350H x4 / C350HI x4
51
Decals / labels / identification plates all markets (USA Market)
STICKER:
JOYSTICK FUNCTION. SUBSTITUTE REF. 10.15003.01
REFERENCE: DESCRIPTION: QUANTITY:
10.15006.01 INDICATIVE STICKER 60X75 1
POSITION:
Stuck on the inside of the right front fender, in the top center position. Just above
sticker ref. 10.15008.01, at 0.1969 in.
STICKER:
JOYSTICK FUNCTION . SUBSTITUTE REF. 10.15005.01
REFERENCE: DESCRIPTION: QUANTITY:
10.15008.01 INDICATIVE STICKER MAST SIDE-SHIFT (USA) 1
POSITION:
Stuck on the inside of the right front fender, in the top center position. Just above
sticker ref. 10.15006.01, at 0.1969 in.
STICKER:
JOYSTICK FUNCTION BUTTONS
REFERENCE: DESCRIPTION: QUANTITY:
10.15009.00
INDICATIVE STICKER AUXILIAR HYDRAULIC LINE ()
1
POSITION:
Stuck on the inside of the right front fender, in the top center position. Just above
sticker ref. 10.15005.01, at 0.1969 in.
