Decals / labels / identification plates all markets (USA Market)
STICKER:
BRAKE FLUID INDICATION
REFERENCE: DESCRIPTION: QUANTITY:
43.70780.01 INDICATIVE STICKER 60x100 BRAKE 1
POSITION:
Into the engine compartment on the external face of the joystick control valve
support, below “Transfer box oil” sticker.
STICKER:
HOT PARTS INDICATION
REFERENCE: DESCRIPTION: QUANTITY:
02.00765.00 INDICATIVE STICKER 40x80 ENGLISH 1
POSITION:
Inside the counterweight, near the exhaust manifold, easily readable when trying
to work on the engine.
STICKER:
LOAD CHART PLATE
REFERENCE: DESCRIPTION: QUANTITY:
43.01350.28 / 30.12004.00 INDICATIVE PLATE 91x156 LOAD CHARTS 1
08243 MANRESA (ESPAÑA)
43.01350.20
AUSA Center, S.L.U.
D cm.
50 60 70 80 90 100 110 120
D
G
G kgs
C300H / C300H x4
MOD.
CARGA MAXIMA EN TERRENO HORIZONTAL
CHARGE ADMISSIBLE EN PALIER
PERMISSIBLE LOAD ON LEVEL
MAX. ZULAESSIGE LAST BEI EBENEM BODEN
3,3
3000
2771
2574
2404
2255
2123
2005
1900
POSITION:
Riveting in 4 holes provided, in the central outer part the left-hand front fender.
Etched according to assembly instruction.
* Add another unit at the top in the event of installing a mast higher than 12ft 14 in.
